Docking Solutions
Shipped across India
We build and install tough, low-maintenance dock levelers, shelters, and loading bridges for safer and faster warehouse loading, all made to fit your site and Indian conditions.
Pricing Guide
Hydraulic Dock Leveler (6 to 10 Ton)
Hardware & Structure
- Platform Deck: High-tensile steel construction with anti-slip checker plate surface (tear plate design).
- Lip Mechanism: Hydraulically operated hinged lip to bridge the gap to the vehicle bed.
- Hydraulic Power Pack: Heavy-duty motor and pump unit with main lifting cylinder and lip cylinder.
- Bumpers: Pair of heavy-duty laminated or molded rubber dock bumpers (approx. 4-inch thickness) to absorb truck impact.
Control & Safety
- Control Panel: Wall-mounted push-button control box with emergency stop and power indicator.
- Safety Features: Full-range toe guards (side skirts) to prevent foot injuries and maintenance support strut.
- Load Capacity: Rated for dynamic loads between 6,000 kg to 10,000 kg.
Installation & Finish
- Finishing: Industrial grade enamel or epoxy paint in safety yellow (moving parts) and black/grey (static parts).
- Documentation: User manual and load test certificate.
Retractable Dock Shelter
Frame & Structure
- Retractable Frame: Collapsible Aluminum or Galvanized Steel frame structure designed to compress upon impact by a misaligned truck, preventing damage.
- Curtains: High-durability PVC fabric curtains (Black) with high tear resistance (Top and Side).
Functionality
- Guide Markings: High-visibility white or yellow stripes on the front curtains to assist drivers in reversing correctly.
- Sealing Efficiency: Covers the gap between the building wall and the truck container.
Environmental Control
- Hygiene Barrier: Prevents ingress of dust, insects, and birds (critical for F&B/Pharma compliance).
- Thermal Insulation: Helps maintain internal warehouse temperature and reduces AC loss.
Mechanical Edge-of-Dock Leveler
Hardware
- Mounting Plate: Heavy-duty steel plate anchored to the existing dock edge.
- Bridge Plate: Checker plate steel flap manually or mechanically lowered onto the truck bed.
- Operation Rod: Manual lever bar used to lift and position the bridge plate using spring assistance.
Specifications
- Capacity: Rated for lighter loads (up to 4,000 kg) suitable for pallet jacks and smaller forklifts.
- Civil Requirement: Zero pit required; bolts onto the existing concrete face.
Safety & Finish
- Bumpers: Includes molded rubber bumper blocks to protect the mechanism from truck impact.
- Finish: Painted in safety yellow for high visibility.
Industrial Goods Lift (G+1 / G+2)
Structural Components
- Lift Cage: Rugged Mild Steel cage construction with honeycomb or wire mesh walls and checker plate flooring.
- Guide Rails: T-section machined guide rails for smooth vertical movement.
- Support Structure: Self-standing steel structure (if civil shaft is not available) or wall-mounted guide brackets.
Drive System
- Drive Type: Hydraulic lifting cylinder (for smooth, heavy lifting) or Traction-based motor system depending on height.
- Capacity: Configurable for 1,000 kg to 2,000 kg loads.
Safety & Automation
- Landing Gates: Manual collapsible gates or swing doors at each floor.
- Interlocks: Electro-mechanical door locks ensuring safety during operation.
- Controls: Floor-mounted call buttons, emergency stop, and overload sensors.
About Docking Solutions
I’ve seen first-hand how a tiny gap between a loading dock and a truck can turn into a big headache - delays, damaged goods, even nasty accidents. At Toshi, we’ve spent 30+ years figuring out ways to make that whole process safer and smoother for everyone on the floor.
What I Offer
- Full range of warehouse dock equipment that’s built tough, so you don’t have to worry about it falling apart mid-shift.
- Dock levelers are the backbone - we’ve got both hydraulic and air bag models, all with anti-slip surfaces and strong enough for the heaviest loads. Just hit a button and get going.
- Industrial dock shelters that keep out dust, rain, insects - essential if you’re running cold storage loading docks or need hygiene for food and pharma work.
- Loading bridges for even easier movement - up to 4000 kg load capacity, with all the right safety bits.
Why Choose Toshi
- Our janbaaz (brave) team actually builds this stuff, not just resells.
- Safety is non-negotiable. Every piece of kit is a rakshak (protector) for your crew.
- Everything’s low maintenance, high on reliability, and tested in real Indian conditions.
I get that every warehouse or plant has its own quirks. That’s why I listen, then put together the right mix for your space. My goal? No drama at your dock - just smooth, fast, and safe movement, every single day.
Meet your Expert
Toshi Automation
98 connects in last 3 months
My Story
Hey, we’re Toshi Automation. Kapil started us up, but really, we’re all about team spirit. My dad’s old-school values—education, helping out—still run deep here. Every year, we do ‘Ashirwad Day’ scholarships for our crew’s kids. Our folks? #Janbaaz in production, #YodhaTeam in sales, #Himmatwale in customer service. We work hard, play harder—think Holi colors, Lohri fires, crazy outdoor ‘Jalsa’. We share, we listen, we grow. That’s our vibe. Success isn’t just numbers, it’s people.
My Work
Entrance and Access Automation - We do self-repairing high-speed doors, customized motorized rolling shutters, automated sliding gates, flap barrier access control, and warehouse docking automation.
Custom Solutions - No cookie-cutter stuff. We match size, color, and finish to your space—home, office, factory, whatever.
Smart Tech, Real Results - Our automation is reliable, safe, and efficient. You’ll see silent shutters, smooth gates, and tech that actually works.
Experience Centre Demo - Ghaziabad में आओ (Come to Ghaziabad), check out live demos with our team. See it before you decide.
Serving All Sectors - From pharma to metros, residential to government—if you need automation, we’re in.
