EPC for Large-Scale Solar Projects
Available across India
We design, build, and manage large-scale solar plants for businesses using our own certified panels, handling everything from start to finish with a 25-year warranty and pan-India support.
Pricing Guide
Standard Commercial On-Grid Solar (Poly/Mono)
Core Hardware
- Solar Modules: Rhine Solar manufactured Standard Monocrystalline or Polycrystalline panels (335Wp - 400Wp). BIS approved and ALMM listed with hard glass front.
- Inverter: Grid-Tie String Inverters from reputed brands (Growatt, Solis, or equivalent). Features >98% efficiency and WiFi/GPRS dongle for app-based monitoring.
Structure & Mounting
- Material: Hot Dip Galvanized Iron (HDGI) structure designed for wind speeds up to 150 km/ph.
- Type: Flush mount (tin shed) or low-height ballast mount (RCC roof). Note: This tier does not include elevated walkways or high-rise structures.
- Hardware: SS-304 grade stainless steel nuts and bolts for rust prevention.
Electrical Safety
- Protection: ACDB and DCDB boxes with necessary MCBs and Surge Protection Devices (SPDs).
- Cabling: UV-resistant DC Solar Cables and Armoured AC Cables from inverter to metering point.
- Earthing: 3-point chemical earthing system (DC, AC, and Lightning Arrester).
- Lightning: Conventional Lightning Arrester mounted on the highest point.
Service & Compliance
- Design: Shadow analysis and 3D structure layout.
- Liaisoning: End-to-end handling of Government Net Metering approvals and DISCOM paperwork.
- Warranties: 25-year performance warranty on Rhine panels, 5-7 years on inverter, and 5-year workmanship warranty.
High-Efficiency Industrial EPC (Mono PERC)
Advanced Technology
- Solar Modules: Rhine Solar Premium Mono PERC Half-Cut Cell Modules (540Wp - 550Wp). 10 Busbar technology for lower resistance and superior low-light performance.
- Inverter: Tier-1 Commercial Grid-Tie Inverters (Sungrow, Huawei, or Solis). Features multiple MPPTs for handling different roof orientations.
Robust Engineering
- Structure: Heavy-duty Hot Dip Galvanized Iron (80 micron coating) designed for higher wind loads of large panels.
- Walkways: Includes basic aluminum or GI walkways for easier cleaning access on large sheds.
- Cable Management: Perforated GI cable trays or conduits to ensure no hanging wires.
Premium Components
- Connectors: Genuine IP68 rated MC4 Connectors (1500V).
- Safety: ESE (Early Streamer Emission) type Lightning Arrester for wider radius protection.
- Durability: Split Junction Box (IP68) with 3 bypass diodes to minimize shading loss.
Execution & Handover
- Design: PVSyst reports showing expected month-on-month generation.
- Approvals: Handling of CEIG (Chief Electrical Inspector) approvals for projects >10kW.
- Cleaning Setup: Provisioning of CPVC water pipelines on the roof with tap points (water source provided by client).
Premium Bifacial Solar Plant (Next-Gen)
State-of-the-Art Generation
- Solar Modules: Rhine Solar Bifacial Modules (Glass-to-Glass or Transparent Backsheet). Generates power from both front and back (albedo), increasing yield by up to 20%.
- Inverter: High-current capacity String Inverters specifically compatible with Bifacial high-amp output.
Specialized Structure
- Elevation: High-rise structure (mounting height >1 meter) to ensure sufficient light reaches the rear side of panels.
- Material: Heavy Gauge Hot Dip Galvanized (min 2mm thickness) or Galvalume construction.
- Optimization: Expert guidance on reflective roof painting to maximize rear-side generation.
Industrial Grade Specs
- Monitoring: Advanced SCADA-ready data logging or granular string-level monitoring apps.
- Safety: Installation of life-line cables along roof edges for cleaning staff safety.
- Grid Safety: Zero Export Device included if required to prevent excess feed-in before net metering activation.
Project Handover
- Documentation: Complete 'As-Built' drawings, test certificates, and component manuals.
- Audit: Thermal imaging of panels at commissioning to verify cell integrity.
- Training: On-site training for client maintenance staff regarding cleaning cycles and troubleshooting.
About EPC for Large-Scale Solar Projects
Solar for Bharat, Solar for Business
I’m all about making solar simple and solid for big Indian businesses. My approach is straightforward - I handle everything so you don’t run around with multiple vendors. From figuring out your site’s needs to flipping the switch on your solar plant, I’m your single point of contact.
What I Do
- Design custom solar solutions for your business site, not just cookie-cutter plans.
- Source every part, build from scratch, and get things done on time.
- Commission and manage your plant so it keeps running smoothly, no extra headaches.
Made in Haryana, Built for Bharat
I manufacture my own panels in Haryana, using tech like bifacial solar module installation and high-efficiency PERC. Every panel is BIS certified, ALMM listed, and TÜV Rheinland tested, so you know it’s safe and reliable for desi (local) conditions - heat, rain, dust, you name it.
Tikau (Durable), Hassle-Free Experience
I design everything to be tikau (long-lasting) and low maintenance. You get a 25-year performance warranty and support for whatever comes up.
Smart Investment for Businesses
Most of my clients save 60-70% on electricity bills. I’ll also guide you through subsidies, tax benefits, and depreciation, because solar isn’t just about saving the planet - it’s about saving money.
Who I Work With
I specialize in turnkey solar EPC solutions for factories, warehouses, offices, and industrial zones pan-India. Pure Bharat, pure solar.
Meet your Expert
Rhine Solar
61 connects in last 3 months
My Story
Namaste, hum Rhine Solar hain – Haryana se, par Bharat bhar mein humara vishwas hai. Shuruaat ek simple soch thi: desh ko apni saaf, sasti urja deni hai, jo har mausam mein chale. Ghar ho ya factory, har jagah humare panels ki roshni pahunche, yahi mission hai. Har panel mein sirf technology nahi, hamara bharosa hai. Hum apne aap ko aapka asli 'solar urja ka saathi' maante hain.
My Work
Solar Solutions for Every Need - Mono PERC rooftop solar panels, bifacial solar modules for industry, OEM manufacturing, EPC services, and dealership – sab kuch milta hai.
Made for Indian Weather - Hamare panels BIS, IEC certified hain, tough Indian conditions ko dhyan mein rakh ke banaye gaye hain.
Har Client Ke Liye Custom Plan - Home, business ya farm – hum aapki zaroorat ke hisaab se solution dete hain.
Quality aur Bharosa - 25+ saal ki performance guarantee, panel ke saath bharosa bhi milta hai.
Pan-India Support - Desh ke kone kone tak Rhine Solar ka expert guidance aur installation support milta hai.
