Rooftop Solar Power Systems
Available across India
We install rooftop solar systems using our own panels, handle everything from site check to switch-on, and offer easy financing so you can cut your electricity bills by up to 90 percent.
Pricing Guide
5kW Residential Grid-Tied System
Core Hardware
- PV Modules: 10 to 12 Orb Energy manufactured Mono PERC panels (500Wp+ each). Made in India with robotic soldering and 25-year performance warranty.
- Inverter: 5kW String Inverter (IP65 rated for outdoors), WiFi-enabled with dual MPPT trackers.
- Structure: Hot Dipped Galvanized Iron (HDGI) elevated structure (4-6 feet high) to ensure the terrace floor remains usable for other activities.
Electrical & Safety
- Cabling: UV-resistant DC Solar Cables and AC connection cables.
- Protection: DC Distribution Box (DCDB) and AC Distribution Box (ACDB) equipped with fuses and Surge Protection Devices (SPD).
- Earthing: Dedicated chemical earthing pits for AC/DC sides and Lightning Arrestor for building protection.
Concierge Services
- Liaisoning: Complete handling of regulatory paperwork for Net Metering and bi-directional meter procurement.
- Installation: Professional setup by Orb-certified technicians with safety gear (helmets/harnesses).
- Support: App setup for monitoring, plus 3 complimentary maintenance visits in the first year.
25kW Commercial Rooftop System
Industrial Grade Assets
- PV Modules: Approx. 50 Orb Energy Mono-PERC / TOPCon modules with 21%+ efficiency to maximize generation on limited roof space.
- Inverter: 25kW Three-Phase Grid-Tied Inverter with active cooling and DG-PV synchronization compatibility.
Structural Engineering
- Mounting: Non-penetrative Klip-lok clamps for metal roofs (leak-proof) or concrete blocks for flat RCC roofs (no drilling).
- Walkways: Dedicated GI/Aluminium mesh walkways installed between panel rows to protect panels from foot traffic.
- Safety Lines: Permanent steel wire ropes running along the array for safety harness attachment.
Compliance & Operations
- Approvals: End-to-end processing of commercial net-metering and CEIG (Chief Electrical Inspector) safety approvals.
- Monitoring: Integration with Remote Operations Center for daily generation auditing.
- Support: 1-year comprehensive preventive maintenance included.
100kW Industrial Power Plant
High-Volume Hardware
- PV Array: 180 to 200 Orb Energy High-Wattage (540Wp+) modules, certified for salt mist and ammonia corrosion.
- Inverter Station: Multiple String Inverters (e.g., 2x 50kW) to ensure partial redundancy during faults.
- Combiner Boxes: Industrial grade IP65/67 polycarbonate enclosures with disconnect switches.
Factory Integration
- Roof Interface: Aluminium rails with EPDM rubber-backed clamps for 100% water-tightness on industrial sheds.
- Cleaning System: UPVC/CPVC piping network installed across the roof with nozzles at strategic points for rapid manual cleaning.
- Cable Trays: Perforated Galvanized Iron cable trays for all cabling to prevent rodent damage.
Grid & Finance
- Liaisoning: Hardware for synchronizing with existing LT panels and complete handling of CEIG safety certificates.
- Asset Documents: Detailed commissioning certificates provided to claim 40% Accelerated Depreciation tax benefits.
- Warranty: 25-year linear power output warranty on panels and 1-year AMC included.
About Rooftop Solar Power Systems
We’ve been helping businesses across India fight rising electricity costs since 2006. If you’re tired of high bijli bills, I get it - the struggle is real. With a rooftop solar power system, you can finally take control and lock in low electricity rates for decades.
What Makes Us Different
- We make our own Mono-Perc solar panels in Bangalore, so quality is totally in our hands. This isn’t just solar panel installation for businesses, it’s a full package.
- Our team handles everything, from checking your site to switching on the system. You don’t have to juggle different vendors or worry about what’s next.
- Need money to get started? We offer collateral-free solar financing with flexible EMIs, no bank drama. Some customers even start saving more than they pay from day one.
Savings & ROI
- Most clients slash their electricity bills by up to 90%.
- The solar power system payback period is usually 3 to 4 years, then it’s pretty much free power for another 20+ years.
- Lower bills, cleaner energy, and a greener brand - especially if you’re targeting international buyers.
Who We Work With
- Factories, rice mills, cold storages, hotels, hospitals, schools, homes with high AC or EV use - you name it, we’ve probably powered it.
Service That Sticks
- Our panels come with a 25-year warranty.
- You can track your system’s power on our solar energy monitoring app.
- We offer reliable AMCs and quick service, because I know things can break and nobody likes waiting.
Meet your Expert
Orb Energy
48 connects in last 3 months
My Story
We kicked off in Bangalore back in 2006, with just a pooja and a dream to make solar easy for everyone. Started out lighting up homes, but soon saw small businesses struggling with crazy electricity bills. So we built our own solar panel plant (Make in India, boss!) and became the first to give collateral-free solar loans. Now, from rice mills in Karnataka to hospitals in Kenya, we've installed solar everywhere. Still feels like we're just getting warmed up.
My Work
Solar Solutions for Every Need - We do rooftop solar for SMEs, ground-mounted parks, solar water heating, and full after-sales AMC service.
Custom Panel Installation - Hamari team comes, checks your site, designs your solar setup, installs with our own panels - no third party drama.
Collateral-Free Solar Loans - No tension about big payments. Our in-house loans mean savings from day one, EMI often less than your old bill.
Reliable After-Sales Support - Annual Maintenance Contract (AMC), quick customer care - as our clients say, 'aapka service mast hai' (your service is awesome).
Who We Help - Perfect for any business or home wanting to cut bills and go green - textiles, agri, schools, hospitals, sabke liye (for everyone).
